Cetane Analyzer FM-CTA-A100

Cetane Analyzer FM-CTA-A100 features a piston stroke of 114.3 mm, ensuring precise and consistent engine operation for accurate cetane number measurements. It includes a single-cylinder, four-stroke engine with a
variable compression ratio for precise fuel testing. This maintains a stable cylinder jacket coolant temperature for engine performance. Our Analyzer has precise temperature controls, ensuring optimal testing conditions for accurate results.

Specifications
Piston Stroke 114.3 mm (4.5 inch)
Range of Compression Ratio 8:1 to 36:1
Inner Diameter of Cylinder 82.55 mm (3.25 inch)
Engine Speed 900 ± 9 r/min

Injection Flow Rate 13.0 ± 0.2 ml/min
Oil Atomizing Advance Angle 13° ± 0.2° (BTDC)
Injector Coolant Passage
Temperature
38 ± 2 ℃
Fuel Pressure 172 to 207 kPa
Fuel Temperature 57 ± 8 ℃
Cylinder Jacket Coolant
Temperature
100 ± 2 ℃
Intake Air Temperature 66 ± 0.5 ℃
Engine Cycling Water
Temperature
≤ Ambient Temp. + 5 ℃
Power Supply 380 VAC ± 10%, 50 Hz, 3
Phase
Power Consumption 10,000 W
Dimensions (L×W×H) 1450 × 720 × 1750 mm
Weight 1000 kg

Features
1. Stable engine speed control
2. Reliable pressure control system
3. Accurate fuel injection system
4. Advanced safety mechanism design
5. Efficient data collection process

Applications
Cetane Analyzer FM-CTA-A100 is used in laboratories, fuel testing facilities, and industries that accurately measure the cetane number of diesel fuels. It applies to diesel fuel quality evaluation, ensuring compliance with international standards and optimal performance.
