NIR-Food Analyzer FM-NIF-A100

NIR- Food Analyzer FM-NIF-A100 operates in the 1000- 1800 nm wavelength range. It processes samples from 50 to 150 ml and includes three cup types. Each test completes in 6 to 10 seconds. It uses diffuse reflectance
for measurements. Designed for ease of use, it simplifies operation with its intuitive interface. The analyzer ensures precise results with its high-performance system.

Specifications
Spectral range 1000 to 1800 nm
Sample volume: Flexible 50 to 150 ml, 3 types of sample
cup
Illumination
source
Tungsten halogen lamp >5000 hours
lifespan

Measurement
mode
Diffuse reflectance
Sensor High-Performance ultra-cooled InGaAs
(Indium Gallium Arsenide) detector to
-25℃
Dual-stage temperature stabilized
Spectral
bandwidth
10.95 ± 0.3 nm @ 1395.5 nm
Baseline noise < 50 μA
Interface USB
Analysis time 6 to 10 sec
Spectral
precision
< 0.1 nm to traceable standard reference
material
Ambient
temperature
5 to 35 ℃
Ambient
humidity
<90% RH
Power Supply 198 to 242 V, frequency 50 Hz, 0.5 A
Dimensions (L
×W ×H)
403 ×391 ×374 mm
Packing
Dimensions
540 × 490 × 470 mm
Gross Weight 25 Kg

Features

1. NIR Food Analyzer with stable performance
2. Tungsten halogen lamp
3. RIMP software integration
4. Test time is under 3 seconds
5. Ultra-cooled In GaAs detector
6. Versatile instrument for multiple products
7. Precise optical bandwidth

Applications

NIR-Food Analyzer is utilized in agriculture, food and beverage, dairy, pharmaceuticals, and animal feed industries.
