To ensure the fastest possible speed of dispensing and good repetition.
• Precise dispensing valve, with maximum accuracy and traceability
• Turn-table design, high speed dispensing
• Gravimetric dispensing, maximum accuracy and traceability
• Automatic detection and warning function
• Easy to change dye solution, no pollution and good expansion
• No need for regular cleaning, no block problem, good reproducibility
• No need for start-up, more convenient for operator
• Windows Software, easy to operate
| Model | CADS MG |
| 120/06 DL | |
| Number of 1L tubeless bottles | 0 |
| Number of 0.8L tubeless bottles | 120+0+0 |
| Total number of tubeless bottles | 120 |
| Number of dedicated aux. bottles | 5 |
| Size of aux. bottles incl. refill | (5L) |
| Number of Scale | 2 |
| Flow rate of tubeless valves (g/min) | 100~240 |
| Power Wattage | 1KVA |
| Control Kernel | PCB |
| Dimensions(WxDxH)(mm) | 2320x1425x1495 |
Layout Drawing：
| • CADS MG 120/06 DL
|
